The Most Versatile VoIP Provider: FREE PORTING

Meet Proxmox: A Virtual Machine Platform for Asterisk



UPDATE: Read our latest Proxmox tutorial: It’s Incredible PBX for Proxmox 7.

More than a decade ago, we introduced the Proxmox virtual machine platform for Asterisk®. Five years later we took another look. Along the way, there have been a few hiccups. But, by and large, Proxmox has had a loyal following for many years. Today we’re pleased to provide an updated tutorial to deploy Proxmox 6.3 with Incredible PBX®. Yes, we know Proxmox 6.4 was released yesterday, but we haven’t had a chance to test it. And, we had a terrific hardware special that’s only available for a short while. We will update this tutorial once we’ve had a chance to run Proxmox 6.4 through its paces.

Why go the virtual machine route? First, you can build Incredible PBX VMs in about one minute. Second, you can make backups and snapshots of your system with the click of a few buttons in the Proxmox GUI. Third, the performance is almost identical to running Incredible PBX on standalone hardware. What’s not to like?

One of our pet peeves with Proxmox has always been the nag screens trying to get you to pay for support. Fortunately, John McLaren solved that with this tutorial. Aside from that, there’s not much not to like about Proxmox. So let’s get started.

This tutorial assumes you have a working Proxmox server. If you don’t and you’re a home or SOHO user, here’s a steal from Amazon that’s only available at the $475.15 price while the remaining inventory is available. It includes a quad-core Intel Core i5 processor with 16GB of RAM, a 512GB NVME SSD drive plus wired and wireless networking. We’ve tried it. It’s great. Installing the Proxmox server from a USB flash drive takes about 5 minutes. This Proxmox tutorial will walk you through building the Proxmox installer with a USB flash drive. Once you have it, plug in a network cable, plug in the flash drive, and turn on the machine while holding down the F7 key. When the drive list appears, choose the USB drive and the Proxmox installer will load. Set up your credentials and fully-qualified domain name and email address, and the rest is just watching the installer work its magic. If you’re tempted to go the Intel NUC route, be advised that Intel and Microsoft have made some BIOS changes which may or may not lead you into harm’s way. Our earlier tutorial has some tips if you run into a snag.

Configuring Proxmox for Incredible PBX VMs

There are three ways you can "talk" to your Proxmox server once it’s up and running: SSH, SFTP, and the Proxmox web GUI. We’ll be using all three. Make note of the IP address assigned to your server during the install procedure.

1. Log into your Proxmox server as root using SSH. Issue the commands in John McLaren’s tutorial to disable the nag screens and restart Proxmox.

2. Download the Debian 10.9 ISO and our Incredible PBX installer (vzdump*.vma.gz) for Proxmox from SourceForge to your desktop.

3. Log into SCP as root using your Proxmox credentials. Using SCP, copy the vzdump*.vma.gz installer to /var/lib/vz/dump on your Proxmox server

4. Using a web browser navigate to https://192.168.0.208:8006/ where 192.168.0.208 is the IP address assigned to your Proxmox server. Login as root using the same root credentials you used with SSH.

5. In the Proxmox GUI, navigate to Datacenter -> Local -> ISO Images -> Upload and upload the Debian 10 ISO from your desktop.

Your Proxmox server now is configured to let you build as many Incredible PBX 2021 virtual machines as you like.

Creating Your First Incredible PBX Virtual Machine



The easiest way to create Incredible PBX 2021 virtual machines is using the Proxmox web GUI. Navigate to Datacenter -> Local -> Backups -> Restore. When the dialog box appears, fill it in as shown below using a unique Proxmox Container Number for each VM (777 in the example). Be sure to tick the Unique box to assure that your VMs don’t step on each other. If you want to start up the VM after creating it, just tick the start up box. When you’re finished, click the Restore button.



In about a minute, your VM will be ready to Start if you didn’t tick the start up box. Once started, click the Console button to open the Incredible PBX console box just as if you had logged in with SSH. For username and password, use root and password. You then will be prompted to change all of your VM’s passwords. New SSH credentials also will be generated. Following the reboot, log back in again with your new root password and let the installer complete its setup. You now have a fully-operational Incredible PBX and Incredible Fax platform. Hop over to the Incredible PBX 2021 tutorial to set up extensions, trunks, and routes.

Originally published: Saturday, May 1, 2021



Need help with Asterisk? Visit the VoIP-info Forum.




Special Thanks to Our Generous Sponsors


FULL DISCLOSURE: ClearlyIP, Skyetel, Vitelity, DigitalOcean, Vultr, VoIP.ms, 3CX, Sangoma, TelecomsXchange and VitalPBX have provided financial support to Nerd Vittles and our open source projects through advertising, referral revenue, and/or merchandise. As an Amazon Associate and Best Buy Affiliate, we also earn from qualifying purchases. We’ve chosen these providers not the other way around. Our decisions are based upon their corporate reputation and the quality of their offerings and pricing. Our recommendations regarding technology are reached without regard to financial compensation except in situations in which comparable products at comparable pricing are available from multiple sources. In this limited case, we support our sponsors because our sponsors support us.

BOGO Bonaza: Enjoy state-of-the-art VoIP service with a $10 credit and half-price SIP service on up to $500 of Skyetel trunking with free number porting when you fund your Skyetel account. No limits on number of simultaneous calls. Quadruple data center redundancy. $25 monthly minimum spend required. Tutorial and sign up details are here.

The lynchpin of Incredible PBX 2020 and beyond is ClearlyIP components which bring management of FreePBX modules and SIP phone integration to a level never before available with any other Asterisk distribution. And now you can configure and reconfigure your new Incredible PBX phones from the convenience of the Incredible PBX GUI.

VitalPBX is perhaps the fastest-growing PBX offering based upon Asterisk with an installed presence in more than 100 countries worldwide. VitalPBX has generously provided a customized White Label version of Incredible PBX tailored for use with all Incredible PBX and VitalPBX custom applications. Follow this link for a free test drive!


Special Thanks to Vitelity. Vitelity is now Voyant Communications and has halted new registrations for the time being. Our special thanks to Vitelity for their unwavering financial support over many years and to the many Nerd Vittles readers who continue to enjoy the benefits of their service offerings. We will keep everyone posted on further developments.




Housekeeping 101: Managing Your Asterisk Backups and Logs



If you’re one of those that likes planting shrubbery but ignores maintenance thereafter, then today’s column is for you. Linux servers and Asterisk® PBXs need some regular attention. If you don’t invest a little time in the backup and log purging tasks, sooner or later you’ll regret it when disaster strikes.

With Incredible PBX® 2020 and 2021 servers, you only have yourself to blame if you don’t make regular backups and move them off site. Simply run /root/incrediblebackup2020 and move the image from /backup to a safe place. For Incredible PBX 16 servers, use the /root/incrediblebackup16 script. If you’re considering a move of your on premise Incredible PBX 2020 or 2021 server to the cloud, then we recommend making a full FreePBX® backup. Simply use the FileStore module in FreePBX in conjunction with the FreePBX Backup module to backup to S3, FTP, SCP, or DropBox. For those using cloud platforms for your PBXs, we strongly recommend investing the few cents more to activate automatic backups or snapshots. See the Incredible PBX Wiki for provider suggestions.

Next, let’s turn to logs. On Linux-based systems running Asterisk, there are literally dozens of logs. If you don’t monitor them carefully, you run the risk of a system failure once your storage device fills up. For PUBLIC implementations of Incredible PBX, you also need to monitor /var/log/secure (CentOS) and /var/log/auth.log (Debian/Ubuntu) for SSH break-in attempts. Monitoring the logs for most other system problems is less necessary because these issues typically will rear their ugly heads in a way that you will instantly know there’s a problem.

That leaves us with taming log creep. Even though many of the logs rotate and manage their own total size, this isn’t true for all of them. The easiest way to identify where your problem areas are is to do full listings of the files in both the /var/log and /var/log/asterisk directories: ls -al /var/log && ls -al /var/log/asterisk. When you see the size of logs creeping into 7 digits or more, it’s time to take corrective action. The simplest way is to build yourself a bash script that runs as a cron job every week or so. Here’s what we typically put in the script. The first few lines clean out the rotated logs, and the other lines initialize all of the current log files except the SSH log. You would obviously want to examine any extremely large logs for issues and security breaches before running this script! We typically create a backup before running the script. This preserves a historical record in case of any problems.

#!/bin/bash
rm -rf /tmp/*
rm -f /var/log/*-2*
rm -f /var/log/asterisk/*-2*
rm -f /var/log/httpd/*-2*
rm -f /var/log/*.gz
rm -f /var/log/asterisk/*.gz
rm -f /var/log/apache2/*.gz
rm -f /var/log/apache2/*.1
rm -f /var/log/*.1
rm -f /var/log/asterisk/*.1
truncate -s 0 /root/.mysql_history
truncate -s 0 /root/.asterisk_history
truncate -s 0 /root/.bash_history
truncate -s 0 /var/log/wtmp
truncate -s 0 /var/log/lastlog
truncate -s 0 /var/log/mysql/error.log
truncate -s 0 /var/log/auth.log
truncate -s 0 /var/log/boot.log
truncate -s 0 /var/log/cron
truncate -s 0 /var/log/cron.log
truncate -s 0 /var/log/daemon.log
truncate -s 0 /var/log/debug
truncate -s 0 /var/log/dmesg
truncate -s 0 /var/log/dmesg.old
truncate -s 0 /var/log/dracut.log
truncate -s 0 /var/log/fail2ban.log
truncate -s 0 /var/log/ipchecker.log
truncate -s 0 /var/log/kern
truncate -s 0 /var/log/kern.log
truncate -s 0 /var/log/knockd.log
truncate -s 0 /var/log/mail.err
truncate -s 0 /var/log/mail.info
truncate -s 0 /var/log/maillog
truncate -s 0 /var/log/mail.warn
truncate -s 0 /var/log/messages
truncate -s 0 /var/log/mysqld.log
truncate -s 0 /var/log/slpd.log
truncate -s 0 /var/log/syslog
truncate -s 0 /var/log/alternatives.log
truncate -s 0 /var/log/bootstrap.log
truncate -s 0 /var/log/dpkg.log
truncate -s 0 /var/log/tallylog
truncate -s 0 /var/log/yum.log
truncate -s 0 /var/log/faillog
truncate -s 0 /var/log/fontconfig.log
truncate -s 0 /var/log/regen_ssh_keys.log
truncate -s 0 /var/log/apache2/access.log
truncate -s 0 /var/log/apache2/error.log
truncate -s 0 /var/log/apache2/other_vhosts_access.log
truncate -s 0 /var/log/asterisk/freepbx_dbug
truncate -s 0 /var/log/asterisk/freepbx_debug
truncate -s 0 /var/log/asterisk/freepbx.log
truncate -s 0 /var/log/asterisk/freepbx_security.log
truncate -s 0 /var/log/asterisk/full
truncate -s 0 /var/log/asterisk/h323_log
truncate -s 0 /var/log/asterisk/messages
truncate -s 0 /var/log/asterisk/queue_log
truncate -s 0 /var/log/asterisk/ucp_out.log
truncate -s 0 /var/log/asterisk/clearlydevices_out.log
truncate -s 0 /var/log/asterisk/clearlysp_out.log
truncate -s 0 /var/log/asterisk/core*.log

To automate this process, create a truncate-logs script in /root with the entries above. Make the script executable: chmod +x /root/truncate-logs. Then add this entry to the bottom of /etc/crontab: 35 4 * * 6 root /root/truncate-logs >/dev/null 2>&1. This would run the script every Saturday morning at 4:35 a.m.

Originally published: Monday, April 26, 2021



Need help with Asterisk? Visit the VoIP-info Forum.




Special Thanks to Our Generous Sponsors


FULL DISCLOSURE: ClearlyIP, Skyetel, Vitelity, DigitalOcean, Vultr, VoIP.ms, 3CX, Sangoma, TelecomsXchange and VitalPBX have provided financial support to Nerd Vittles and our open source projects through advertising, referral revenue, and/or merchandise. As an Amazon Associate and Best Buy Affiliate, we also earn from qualifying purchases. We’ve chosen these providers not the other way around. Our decisions are based upon their corporate reputation and the quality of their offerings and pricing. Our recommendations regarding technology are reached without regard to financial compensation except in situations in which comparable products at comparable pricing are available from multiple sources. In this limited case, we support our sponsors because our sponsors support us.

BOGO Bonaza: Enjoy state-of-the-art VoIP service with a $10 credit and half-price SIP service on up to $500 of Skyetel trunking with free number porting when you fund your Skyetel account. No limits on number of simultaneous calls. Quadruple data center redundancy. $25 monthly minimum spend required. Tutorial and sign up details are here.

The lynchpin of Incredible PBX 2020 and beyond is ClearlyIP components which bring management of FreePBX modules and SIP phone integration to a level never before available with any other Asterisk distribution. And now you can configure and reconfigure your new Incredible PBX phones from the convenience of the Incredible PBX GUI.

VitalPBX is perhaps the fastest-growing PBX offering based upon Asterisk with an installed presence in more than 100 countries worldwide. VitalPBX has generously provided a customized White Label version of Incredible PBX tailored for use with all Incredible PBX and VitalPBX custom applications. Follow this link for a free test drive!


Special Thanks to Vitelity. Vitelity is now Voyant Communications and has halted new registrations for the time being. Our special thanks to Vitelity for their unwavering financial support over many years and to the many Nerd Vittles readers who continue to enjoy the benefits of their service offerings. We will keep everyone posted on further developments.




Taming the Condo Call Box with a Raspberry Pi & Asterisk



If you live in an apartment complex or condominium with a call box to let visitors gain door access by calling your apartment, then today’s column is for you. The way almost all of these call boxes work is the management company programs your name, phone number, and apartment number into the call box after which a visitor can look up your name or enter your apartment number and the call box will call you. When you answer the call and press 9 on your phone, the apartment door will unlock momentarily allowing the visitor to enter the building. But what if you don’t answer the call and a delivery driver needs to drop off your check from Publisher’s Clearinghouse? Or suppose you or a significant other has gone jogging without a cellphone and locked yourself out of the building? Well, worry no more. With Asterisk and a $35 Raspberry Pi running Incredible PBX, you can conquer the call box and let anybody into the building without ever touching your phone. All you need is an access code.

We will assume that you have a functioning Incredible PBX server with at least one incoming phone number. If not, start here. Then provide the management company with your 10-digit DID to assign to the call box. Once it’s set up, use the call box to call yourself and review the call detail records on your PBX to decipher the callbox’s actual phone number.

You do NOT need a dedicated DID to answer Call Box incoming calls. Deploying the script below will tell Asterisk to intercept calls from the Call Box for special processing and pass the rest of your incoming calls to your DID’s preconfigured Inbound Route. When a Call Box call is detected by its CallerID Number, the script will prompt the visitor to enter a security code. If the code entered is valid, a DTMF tone simulating the pressing of 9 on your phone will be sent to the Call Box to open the door, and the visitor will be advised that the door is being unlocked. If the visitor enters an invalid access code three times in a row, Asterisk will hang up the call from the Call Box. Easy peasy!

Now let’s reconfigure your Asterisk PBX to manage incoming calls from the Call Box. You’ll need (1) the 10-digit DID that you provided to the management company for calls from the CallBox. (2) the 10-digit phone number that the Call Box uses to call you, and (3) a security PIN which the visitor must enter to gain door access. In the sample code below, (1) substitute your 10-digit DID for 8881234567 on the 14 lines (twice on lines 3 and 5), (2) substitute the Call Box 10-digit phone number for 9990000000 on line 4, (3) in line 7 replace 90210 with the security PIN you want visitors to enter to gain door access, and (4) enter your email address on line 11 replacing yourname@gmail.com so you’re notified when visitors arrive.

[from-callbox]
exten => 8881234567,1,Answer
exten => 8881234567,n,Wait(1)
exten => 8881234567,n,NoOp(*** Incoming call on 8881234567 DID ***)
exten => 8881234567,n,GotoIf($["${CALLERID(number)}" = "9990000000"]?BUZZMEUP)
exten => 8881234567,n,Goto(from-trunk,8881234567,1)
exten => 8881234567,n,Hangup
exten => 8881234567,n(BUZZMEUP),Authenticate(90210)
exten => 8881234567,n,Playback(access-granted)
exten => 8881234567,n,agi(picotts.agi,"The door is opening. Please come in.")
exten => 8881234567,n,SendDTMF(9,50,2000)
exten => 8881234567,n,system(echo "Condo door opened" | /usr/bin/mail -s ALERT yourname@gmail.com)
exten => 8881234567,n,Wait(3)
exten => 8881234567,n,Playback(goodbye)
exten => 8881234567,n,Hangup
exten => s,1,Hangup
;-------------------------------------------------------------------------

Next, copy the edited code to the end of /etc/asterisk/extensions_custom.conf and reload your dialplan: asterisk -rx "dialplan reload".

Finally, using a browser, open the FreePBX GUI. Edit the trunk corresponding to your DID above and change the context to from-callbox. Also make certain you have an Inbound Route for your 10-digit DID to redirect non-CallBox calls to whatever destination is desired.

Now leave your building (with your key) and use the Call Box to test your new setup. Enjoy!

Originally published: Monday, April 5, 2021



Need help with Asterisk? Visit the VoIP-info Forum.




Special Thanks to Our Generous Sponsors


FULL DISCLOSURE: ClearlyIP, Skyetel, Vitelity, DigitalOcean, Vultr, VoIP.ms, 3CX, Sangoma, TelecomsXchange and VitalPBX have provided financial support to Nerd Vittles and our open source projects through advertising, referral revenue, and/or merchandise. As an Amazon Associate and Best Buy Affiliate, we also earn from qualifying purchases. We’ve chosen these providers not the other way around. Our decisions are based upon their corporate reputation and the quality of their offerings and pricing. Our recommendations regarding technology are reached without regard to financial compensation except in situations in which comparable products at comparable pricing are available from multiple sources. In this limited case, we support our sponsors because our sponsors support us.

BOGO Bonaza: Enjoy state-of-the-art VoIP service with a $10 credit and half-price SIP service on up to $500 of Skyetel trunking with free number porting when you fund your Skyetel account. No limits on number of simultaneous calls. Quadruple data center redundancy. $25 monthly minimum spend required. Tutorial and sign up details are here.

The lynchpin of Incredible PBX 2020 and beyond is ClearlyIP components which bring management of FreePBX modules and SIP phone integration to a level never before available with any other Asterisk distribution. And now you can configure and reconfigure your new Incredible PBX phones from the convenience of the Incredible PBX GUI.

VitalPBX is perhaps the fastest-growing PBX offering based upon Asterisk with an installed presence in more than 100 countries worldwide. VitalPBX has generously provided a customized White Label version of Incredible PBX tailored for use with all Incredible PBX and VitalPBX custom applications. Follow this link for a free test drive!


Special Thanks to Vitelity. Vitelity is now Voyant Communications and has halted new registrations for the time being. Our special thanks to Vitelity for their unwavering financial support over many years and to the many Nerd Vittles readers who continue to enjoy the benefits of their service offerings. We will keep everyone posted on further developments.




One-Minute Wonder: It’s Incredible PBX 2021 for VirtualBox




If you’re new to the VoIP world and want to kick the tires to see what you’re missing, then today’s one minute setup is for you. You’ll get a $10 credit to try out some penny-a-minute calls and to purchase a $1 a month phone number in your choice of area codes. If you decide VoIP is not for you, you don’t have to buy anything ever. And you can use almost any desktop computer you already own to bring up the VirtualBox® edition of Incredible PBX® 2021.

If you’ve followed Nerd Vittles over the years, you already know that VirtualBox from Oracle® is one of our favorite platforms. Once VirtualBox is installed on your desktop computer, adding Incredible PBX is a snap. Download the latest Incredible PBX 2021 image from SourceForge, double-click on the downloaded image, check the initialize MAC address box, and boom. In less than a minute, your PBX is ready to use with the very latest components of Asterisk® 18 and FreePBX® 15. There are no hidden fees or crippleware to hinder your use of Incredible PBX for as long as you like. Just set up an account with our Platinum provider, Skyetel, and you can start making calls in minutes. Of course, the Incredible PBX feature set is included as well which brings you nearly three dozen applications for Asterisk that will revolutionize your communications platform. Speech-to-text, voice recognition, and a Siri-like telephony interface are as close as your SIP phone.

Installing Oracle VM VirtualBox

Oracle’s virtual machine platform inherited from Sun is amazing. It’s not only free, but it’s pure GPL2 code. VirtualBox gives you a virtual machine platform that runs on top of any desktop operating system. In terms of limitations, we haven’t found any. We even tested this on an Atom-based Windows 7 machine with 2GB of RAM, and it worked without a hiccup. So step #1 today is to download one or more of the VirtualBox installers from VirtualBox.org or Oracle.com. Our recommendation is to put all of the 100MB installers on a 4GB thumb drive.1 Then you’ll have everything in one place whenever and wherever you happen to need it. Once you’ve downloaded the software, simply install it onto your favorite desktop machine. Accept all of the default settings, and you’ll be good to go. For more details, here’s a link to the Oracle VM VirtualBox User Manual.

NOTE: The Incredible PBX 2021 VM requires a VirtualBox 6.x platform. Adjust screen size in View -> Virtual Screen.

Installing the Incredible PBX 2021 Image

To begin, download the Incredible PBX 2021 image (3.1 GB) onto your desktop.

Next, double-click on the Incredible PBX .ova image on your desktop. Be sure to check the box to initialize the MAC address of the image if you’re using an older version of VirtualBox. Then click Import. Once the import is finished, you’ll see a new Incredible PBX 2021 virtual machine in the VM List of the VirtualBox Manager Window. Let’s make a couple of one-time adjustments to the Incredible PBX configuration to account for possible differences in sound and network cards on different host machines.

(1) Click once on the Incredible PBX virtual machine in the VM List. Then (2) click the Settings button. In System tab, check Hardware Clock in UTC Time. In the Audio tab, check the Enable Audio option and choose your sound card. In the Network tab for Adapter 1, check the Enable Network Adapter option. From the Attached to pull-down menu, choose Bridged Adapter. Then select your network card from the Name list. Then click OK. That’s all the configuration that is necessary for Incredible PBX.

Running Incredible PBX 2021 in VirtualBox

Once you’ve imported and configured the Incredible PBX Virtual Machine, you’re ready to go. Highlight the Incredible PBX virtual machine in the VM List on the VirtualBox Manager Window and click the Start button. The standard Linux boot procedure will begin and, within a few seconds, you’ll get the familiar Linux login prompt. During the bootstrap procedure, you’ll see a couple of dialogue boxes pop up that explain the keystrokes to move back and forth between your host operating system desktop and your virtual machine. Remember, you still have full access to your desktop computer. Incredible PBX is merely running as a task in a VM window. Always gracefully halt Incredible PBX just as you would on any computer.

Here’s what you need to know. To work in the Incredible PBX virtual machine, just left-click your mouse while it is positioned inside the VM window. To return to your host operating system desktop, press the right Option key on Windows machines or the left Command key on any Mac. On Linux desktops, press the right Ctrl key. For other operating systems, read the dialogue boxes for instructions on moving around. To access the Linux CLI, login as root with the default password: password. Change your root password when you are prompted to do so. Then update your admin password for web access: ./admin-pw-change. Also update your admin password for web applications: ./apache-pw-change. You’ll need these admin passwords to access the web GUI to manage your PBX as well as to use the AsteriDex and Reminders web apps. The above password updates are automatically requested when you first activate the virtual machine. You can update all of your other passwords using the scripts provided in /root. For example, you’ll want to set the email delivery address for incoming faxes by running: ./avantfax-email-change. And set the AvantFax admin password by running: ./avantfax-pw-change. When running the AvantFax web application, be advised that you first will be prompted for your Apache admin credentials. Then you will be prompted for your AvantFax admin credentials.

Setting the Date and Time with VirtualBox

On some platforms, VirtualBox has a nasty habit of mangling the date and time of your virtual machine. Verify that you have enabled the Hardware Clock in UTC Time option for your virtual machine as documented above. If pbxstatus still shows an incorrect time, manually set the date and time and then update the hardware clock. Here’s how assuming 08130709 is the month (August), day (13), and correct time (7:09 a.m.) of your server:

date 08130709
clock -w

Configuring Skyetel for Incredible PBX 2021

If you’d like to try out the Skyetel service at no charge, here’s the drill. Sign up for Skyetel service to take advantage of the Nerd Vittles specials. First, complete the Prequalification Form here. You then will be provided a link to the Skyetel site to complete your registration. Once you have registered on the Skyetel site and your account has been activated, open a support ticket and request the $10 credit for your account by referencing the Nerd Vittles special offer. Once you are satisfied with the service, fund your account as desired, and Skyetel will match your deposit of up to $250 simply by opening another ticket. That gets you up to $500 of half-price calling. Credit is limited to one per person, company, and address. Effective 10/1/2023, $25/month minimum spend required.

Skyetel does not use SIP registrations to make connections to your PBX. Instead, Skyetel utilizes Endpoint Groups to identify which servers can communicate with the Skyetel service. An Endpoint Group consists of a Name, an IP address, a UDP or TCP port for the connection, and a numerical Priority for the group. For incoming calls destined to your PBX, DIDs are associated with an Endpoint Group to route the calls to your PBX. For outgoing calls from your PBX, a matching Endpoint Group is required to authorize outbound calls through the Skyetel network. Thus, the first step in configuring the Skyetel side for use with your PBX is to set up an Endpoint Group. Here’s a typical setup for Incredible PBX 16-15:

  • Name: MyPBX
  • Priority: 1
  • IP Address: PBX-Public-IP-Address
  • Port: 5060
  • Protocol: UDP
  • Description: my.incrediblepbx.com

To receive incoming PSTN calls, you’ll need at least one DID. On the Skyetel site, you acquire DIDs under the Phone Numbers tab. You have the option of Porting in Existing Numbers (free for the first 60 days after you sign up for service) or purchasing new ones under the Buy Phone Numbers menu option.

Once you have acquired one or more DIDs, navigate to the Local Numbers or Toll Free Numbers tab and specify the desired SIP Format and Endpoint Group for each DID. Add SMS/MMS and E911 support, if desired. Call Forwarding and Failover are also supported. That completes the VoIP setup on the Skyetel side. System Status is always available here.

If VirtualBox is sitting behind a router or firewall on a private LAN, you’ll need to forward ports UDP 5060 and 10000-20000 in your router to the private LAN address of your Incredible PBX server. Also edit your extensions in the GUI and set NAT=YES in the Advanced tab of every extension. In Settings -> Asterisk SIP Settings, click the Detect Network Settings button and then Submit your changes and reload the Asterisk dialplan when prompted.

Configuring VoIP.ms for Incredible PBX 2021

To sign up for VoIP.ms service, may we suggest you use our signup link so that Nerd Vittles gets a referral credit for your signup. Once your account is set up, you’ll need to set up a SIP SubAccount and, for Authentication Type, choose Static IP Authentication and enter your Incredible PBX 2021 server’s public IP address. For Transport, choose UDP. For Device Type, choose Asterisk, IP PBX, Gateway or VoIP Switch. Order a DID in their web panel, and then point the DID to the SubAccount you just created. Be sure to specify atlanta1.voip.ms as the POP from which to receive incoming calls.

Configuring V1VoIP for Incredible PBX 2021

To sign up for V1VoIP service, sign up on their web site. Then login to your account and order a DID under the DIDs tab. Once the DID has been assigned, choose View DIDs and click on the Forwarding button beside your DID. For Option #1, choose Forward to IP Address/PBX. For the Forwarding Address, enter the public IP address of your server. For the T/O (timeout) value, set it to 2o seconds. Then click the Update button. Under the Termination tab, create a new Endpoint with the public IP address of your server so that you can place outbound calls through V1VoIP.

Configuring Anveo Direct for Incredible PBX 2021

To sign up for Anveo Direct service, sign up on their web site and then login. After adding funds to your account, purchase a DID under Inbound Service -> Order DID. Next, choose Configure Destination SIP Trunk. Give the Trunk a name. For the Primary SIP URI, enter $[E164]$@server-IP-address. For Call Options, select your new DID from the list. You also must whitelist your public IP address under Outbound Service -> Configure. Create a new Call Termination Trunk and name it to match your server. For Dialing Prefix, choose six alphanumeric characters beginning with a zero. In Authorized IP Addresses, enter the public IP address of your server. Set an appropriate rate cap. We like $0.01 per minute to be safe. Set a concurrent calls limit. We like 2. For the Call Routing Method, choose Least Cost unless you’re feeling extravagant. For Routes/Carriers, choose Standard Routes. Write down your Dialing Prefix and then click the Save button.

Before you can make outbound calls through Anveo Direct from your PBX, you first must configure the Dialing Prefix that you wrote down in the previous step. Log into the GUI as admin using a web browser and edit the Anveo-Out trunk in Connectivity -> Trunks. Click on the custom-Settings tab and replace anveo-pin with your actual Dialing Prefix. Click Submit and Apply Config to complete the setup.

By default, incoming Anveo Direct calls will be processed by the Default inbound route on your PBX. If you wish to redirect incoming Anveo Direct calls using DID-specific inbound routes, then you’ve got a bit more work to do. In addition to creating the inbound route using the 11-digit Anveo Direct DID, enter the following commands after logging into your server as root using SSH/Putty:

cd /etc/asterisk
echo "[from-anveo]" >> extensions_custom.conf
echo "exten => _.,1,Ringing" >> extensions_custom.conf
echo "exten => _.,n,Goto(from-trunk,\\${SIP_HEADER(X-anveo-e164)},1)" >> extensions_custom.conf
asterisk -rx "dialplan reload"

Configuring a Softphone for Incredible PBX 2021

We’re in the home stretch now. You can connect virtually any kind of telephone to your new PBX. Plain Old Phones require an analog telephone adapter (ATA) which can be a separate board in your computer from a company such as Digium. Or it can be a standalone SIP device such as ObiHai’s OBi100 or OBi110 (if you have a phone line from Ma Bell to hook up as well). SIP phones can be connected directly so long as they have an IP address. These could be hardware devices or software devices such as the YateClient softphone. We’ll start with a free one today so you can begin making calls. You can find dozens of recommendations for hardware-based SIP phones both on Nerd Vittles and the PIAF Forum when you’re ready to get serious about VoIP telephony.

We recommend YateClient for Windows which is free. Download it from here. Run YateClient once you’ve installed it and enter the credentials for the 701 extension on Incredible PBX. You can find them by running /root/show-passwords. You’ll need the IP address of your server plus your extension 701 password. In the YateClient, fill in the blanks using the IP address of your Server, 701 for your Username, and whatever Password was assigned to the extension when you installed Incredible PBX. Click OK to save your entries.

Configuring Incredible PBX 2021 for VirtualBox

In order to take advantage of all the Incredible PBX applications, you’ll need to obtain IBM text-to-speech (TTS) and speech-to-text (STT) credentials as well as a (free) Application ID for Wolfram Alpha.

This Nerd Vittles tutorial will walk you through getting your IBM account set up and obtaining both your TTS and STT credentials. Be sure to write down BOTH sets of credentials which you’ll need in a minute. For home and SOHO use, IBM access and services are mostly FREE even though you must provide a credit card when signing up. The IBM signup process explains their pricing plans.

To use Wolfram Alpha, sign up for a free Wolfram Alpha API account. Just provide your email address and set up a password. It takes less than a minute. Log into your account and click on Get An App ID. Make up a name for your application and write down (and keep secret) your APP-ID code. That’s all there is to getting set up with Wolfram Alpha. If you want to explore costs for commercial use, there are links to let you get more information.

In addition to your Wolfram Alpha APPID, there are two sets of IBM credentials to plug into the Asterisk AGI scripts. Keep in mind that there are different usernames and passwords for the IBM Watson TTS and STT services. The TTS credentials will look like the following: $IBM_username and $IBM_password. The STT credentials look like this: $API_USERNAME and $API_PASSWORD. Don’t mix them up. 🙂

All of the scripts requiring credentials are located in /var/lib/asterisk/agi-bin so switch to that directory after logging into your server as root. Edit each of the following files and insert your TTS credentials in the variables already provided: nv-today2.php, ibmtts.php, and ibmtts2.php. Edit each of the following files and insert your STT credentials in the variables already provided: getquery.sh, getnumber.sh, and getnumber2.sh. Finally, edit 4747 and insert your Wolfram Alpha APPID.

Using AsteriDex with Incredible PBX

AsteriDex is a web-based dialer and address book application for Asterisk and Incredible PBX. It lets you store and manage phone numbers of all your friends and business associates in an easy-to-use SQLite3 database. You simply call up the application with your favorite web browser: http://pbx-ip-address/asteridex4/. When you click on a contact that you wish to call, AsteriDex first calls you at extension 701, and then AsteriDex connects you to your contact through another outbound call made using your default outbound trunk that supports numbers in the 1NXXNXXXXXX format.

Keeping FreePBX 15 Modules Current

We strongly recommend that you periodically update all of your FreePBX modules to eliminate bugs and to reduce security vulnerabilities. From the Linux CLI, log into your server as root and issue the following commands:

rm -f /tmp/*
fwconsole ma upgradeall
fwconsole reload
/root/sig-fix
systemctl restart apache2
/root/sig-fix

Taking Incredible PBX for a Test Drive

You can take Incredible PBX on a test drive by dialing D-E-M-O (3366) from any phone connected to your PBX.

With Allison’s Demo IVR, you can choose from the following options:

  • 0. Chat with Operator — connects to extension 701
  • 1. AsteriDex Voice Dialer – say "Delta Airlines" or "American Airlines" to connect
  • 2. Conferencing – log in using 1234 as the conference PIN
  • 3. Wolfram Alpha Almanac – say "What planes are flying overhead"
  • 4. Lenny – The Telemarketer’s Worst Nightmare
  • 5. Today’s News Headlines — courtesy of Yahoo! News
  • 6. Weather by ZIP Code – enter any 5-digit ZIP code for today’s weather
  • 7. Today in History — courtesy of OnThisDay.com
  • 8. Chat with Nerd Uno — courtesy of SIP URI connection to 3CX iPhone Client
  • 9. DISA Voice Dialer — say any 10-digit number to be connected
  • *. Current Date and Time — courtesy of Incredible PBX

Originally published: Sunday, March 28, 2021  Updated: Tuesday, November 30, 2021



Need help with Asterisk? Visit the VoIP-info Forum.






  1. Many of our purchase links refer users to Amazon when we find their prices are competitive for the recommended products. Nerd Vittles receives a small referral fee from Amazon to help cover the costs of our blog. We never recommend particular products solely to generate Amazon commissions. However, when pricing is comparable or availability is favorable, we support Amazon because Amazon supports us. []

SPAM Blocker & CNAM Cornucopia for Incredible PBX 2021




If you enjoy calls from politicians and car warranty offers as much as we do, then today’s your lucky day. Blocking spam phone calls has been a challenge to put it charitably. Thanks to some earlier work by Stewart Nelson on the DSLR forum as well as Stewart’s considerable hand-holding in the development of our previous tutorials, we want to introduce an updated call screening approach for Incredible PBX 2021 that takes into account some recent changes in FreePBX® design. In a nutshell, the previous implementation no longer works because of some FreePBX plumbing changes that eliminated the "hook" we were using to intercept and screen incoming calls.

If you missed the earlier article, here’s the design. First time callers that are not on your WhiteList will be prompted to "press 5 to connect." Since most spam calls sit in a queue for several seconds before a live person chimes in, that person won’t hear the prompt. After 10 seconds or an invalid response, the call is sent to voicemail. In the alternative, you can play a SIT tone and disconnect the call or you can send the call to your favorite uncle, Lenny. When a successful caller calls again, the caller will be connected without a prompt. Once installed, you can change the voice prompt to a number other than 5 by modifying lines 11 and 13 of the context [sub-log-caller] which you will find in extensions_custom.conf in the /etc/asterisk directory at the completion of this install.

While today’s approach won’t block every robocaller, our testing suggests that it will catch more than 95% of these annoying calls. Using CallerID Superfecta coupled with the Asterisk® Phanebook will provide an extremely low-cost solution both for blocking spammers AND for displaying accurate CNAM data for incoming calls. The silver lining is you’ll only pay for CNAM lookups from legitimate callers once, and you have a choice of using OpenCNAM or BulkCNAM with the scripts we’ll provide today. Last, but not least, you’ll also get CNAM data for outgoing calls in your CDR logs.

Here’s the actual dialplan addition that will monitor your incoming calls:

[sub-log-caller]
exten => s,1,NoOp(*** begin sub-log-caller ***)
exten => s,n,Set(email='root')
exten => s,n,GotoIf($['${MESSAGE(from)}' != '']?SMSINCOMING)
exten => s,n,GotoIf(${DB_EXISTS(cidname/${CALLERID(num)})}?CNAMOK)
;exten => s,n,Goto(WHITELISTED)
exten => s,n,GotoIf($[${DB(SPAMCHECK/deactivate)} = 1]?CONNECTNOW)
exten => s,n,GotoIf($[${DB(cidname/0)} = SPAMCHECK]?CONNECTNOW)
exten => s,n,Playback(silence/1)
;exten => s,n,Goto(ANONTEST)
exten => s,n,Playback(custom/press5)
exten => s,n,Read(MYCODE,beep,1,n,1,10)
exten => s,n,GotoIf($["${MYCODE}" = "5"]?ANONTEST)
exten => s,n(FLUNKED),NoOp(*** Caller FLUNKED screening ***)
exten => s,n,Dial(local/*701@from-internal) ; uncomment to send to 701 VM
;exten => s,n,Dial(local/53669@from-internal) ; uncomment to send to Lenny
exten => s,n,Zapateller()
exten => s,n,Hangup
exten => s,n,Return()
exten => s,n(SMSINCOMING),NoOp(${MESSAGE(from)})
exten => s,n,NoOp(${MESSAGE(body)})
exten => s,n,GotoIf($["${email}" = "root"]?NOEMAIL)
exten => s,n,system(echo "FROM: ${MESSAGE(from)} \nVIA: ${CDR(did)} \n${MESSAGE(body)}" | `/usr/bin/which mail` -s "Incoming SMS Message" ${email})
;exten => s,n,SendText("Received but cannot reply now.")
exten => s,n(NOEMAIL),Hangup
exten => s,n,Return()
exten => s,n(CNAMOK),Set(CALLERID(name)=${DB(cidname/${CALLERID(number)})})
exten => s,n,Goto(WHITELISTED)
exten => s,n(ANONTEST),GotoIf($[${CALLERID(num)} > 0]?WHITELISTNOW:CONNECTNOW)
exten => s,n(WHITELISTNOW),Set(DB(cidname/${CALLERID(number)})=${CALLERID(name)})
exten => s,n,Set(CALLERID(all)="${CALLERID(name)} <${CALLERID(number)}>")
exten => s,n,Goto(SENDEMAIL)
exten => s,n(WHITELISTED),Set(CALLERID(all)="${CALLERID(name)} <${CALLERID(number)}>")
exten => s,n,Goto(CONNECTNOW)
exten => s,n(SENDEMAIL),NoOp(WhiteListed: ${CALLERID(all)})
exten => s,n,GotoIf($["${email}" = "root"]?CONNECTNOW)
exten => s,n,system(echo "In Asterisk Phone Book, verify new CNAM entry of ${CALLERID(name)} for ${CALLERID(number)}." | `/usr/bin/which mail` -s "Incredible PBX CNAM Reminder" ${email})
exten => s,n(CONNECTNOW),NoOp(*** end of sub-log-caller ***)
exten => s,n,Return()
;-------------------------------------------------------------------------------


The beauty of today’s design is that it won’t interfere with your existing call processing rules. In other words, FreePBX Inbound Routes sent to IVRs, Ring Groups, Conferences, and even incoming Faxes still will be processed exactly as they have been in the past once the CallerID number makes it onto your WhiteList. Unlike the previous design which tweaked the FreePBX Core module slightly, today’s implementation uses a slightly modified [app-blacklist-check] context to kick off our screening component above. This eliminates the need to modify the core module each time FreePBX updates the module. We’ve also enhanced the install to support those using the new Incredible PBX 2021 PUBLIC platform. This gives you the same SPAM protection for calls reaching your PBX directly via a SIP URI instead of a commercial DID.

Here are the basic steps to get this working:

  1. Configure and Enable CallerID Superfecta in FreePBX
  2. Enable CallerID Superfecta on All Inbound Routes
  3. Set the Proper Context for Your Trunks
  4. Download & Install Call Screener 2021
  5. Import Previous Callers into WhiteList

1. Configuring CallerID Superfecta in FreePBX

CallerID Superfecta is an integral component in today’s new call screening design. It will be used both to populate the Asterisk Phonebook’s WhiteList and to provide CallerID Name (CNAM) data about your callers while assuring that you only pay for one CNAM query even though grandma may call you a dozen times a day. We use the Asterisk Phonebook as the whitelist of authorized callers. The way CallerID Superfecta works is it checks multiple sources for a match on the incoming CallerID Number. As soon as a match is found, the checking ends and the CallerID Number and Name are passed to the Call Screening script.

The CallerID Superfecta lookup sequence needs to be set as follows in the United States: AsteriDex (if desired), Asterisk Phonebook (required), and then one of the following commercial CNAM lookup services: OpenCNAM or BulkCNAM. In other countries, there still may be free CNAM services, but they’ve all disappeared in the U.S. market. We’ve documented the other available sources in a previous Nerd Vittles article.

Low-volume OpenCNAM Value pricing provides global lookups for $0.0028 each. BulkCNAM provides CNAM queries with RoboCall identification for $0.002 per query. If you sign up with OpenCNAM, you will need your Account SID and Auth Token to configure CallerID Superfecta and to populate the Call Screening script. If you sign up with BulkVS, you will need your API Key from the API Credentials tab in your BulkVS Dashboard.

With your credentials in hand, login into FreePBX as admin and navigate to Admin -> CID Superfecta -> Default. Arrange and enable the lookup sources in the following order: AsteriDex, Asterisk Phonebook, and then either OpenCNAM or BulkCNAM (in the U.S. market) or your country’s best CNAM lookup source. Be sure to enter your credentials for the CNAM provider by clicking on the wrench icon beside the provider. If your incoming trunks already provide CNAM lookups (such as BulkVS and Incredible PBX Trunking), then you can substitute Trunk Provided as your CNAM lookup service. With Incredible PBX Trunking, in addition to free CNAM lookups, you also get SPAM detection at no additional cost. For details on the service, follow this link. Then we typically set Telco Data as the last lookup source which will at least give you the city and state of the caller.

2. Enabling CallerID Superfecta on Inbound Routes

By default, CallerID Superfecta is not enabled for incoming calls to your PBX. You must enable it on every Inbound Route by navigating to Connectivity -> Inbound Routes and then editing each of your routes. Then click on the Other tab and set Enable Superfecta Lookup to YES and set the Superfecta Scheme to DEFAULT. Click SUBMIT to save your route settings and then reload the dialplan when prompted.

3. Setting the Proper Context for Your Trunks

It’s equally important to make certain that the CallerID Numbers for all of your incoming calls arrive in the same format. Computers are stupid. 8005551212 and 18005551212 and +18005551212 are completely different callers as far as your PBX is concerned. If different trunks deliver calls with CallerID Numbers formatted differently, then you would need to whitelist ALL of the various permutations for every caller in the Asterisk Phonebook. For those in the U.S. and Canada that primarily receive calls from the U.S. and Canada, we recommend setting the context entry in every trunk to from-pstn-e164-us. This will handle the translation of all 3 number formats above into 10-digit numbers. Calls from other countries will not be affected.

4. Downloading & Installing Call Screener 2021

Now let’s put all the Call Screener components in place and configure the screening setup to meet your own requirements. To get started, log into Incredible PBX as root and issue the following commands:

mkdir /tmp/CALL-SCREENER
cd /tmp/CALL-SCREENER
wget http://incrediblepbx.com/CallScreener2021.tar.gz
tar zxvf CallScreener2021.tar.gz
rm -f CallScreener2021.tar.gz
./install

Once the install is begun, the editor will open to the dialplan code. In the [sub-log-caller] context, you have a few options. First, you need to choose how to handle incoming calls where the caller does not enter the "press5″ number prompt in a timely manner. The default setup (line 14) sends these callers to voicemail for extension 701. You can change the voicemail extension, or you can elect to treat the calls differently. We’ve provided two additional options. Line 15 will send the calls to Lenny at extension 53669. Line 16 will send the calls to Zapateller which is the universal tone for numbers that are not in service. You should enable only one of these three options and comment out the other two by placing a semicolon (;) at the start of the other two lines. If you have fax detection enabled on your PBX, you probably would not want to send failed calls to either Lenny or Zapateller since you may never know the incoming faxes failed. Similarly, if you get calls from people with rotary dial phones such as Grandma, you probably don’t want her talking to Lenny or listening to Zapateller tones.

The next option is which number to prompt callers to press. The default is 5. But you can change it by modifying the existing press5 entry on line 10 and entering the number to match on line 12. Available choices are 5 through 9.

The final option in the [sub-log-caller] context is to activate email notifications for new callers that pass the screening test. This is especially important if you receive lots of calls from cellphone users. Most of those calls will arrive with a CNAM entry of nothing more than the caller’s City and State. Activating an email reminder will notify you to update the Asterisk Phonebook entry for such callers to replace the City, State entry with the caller’s actual name so that your CDR listings and future calls provide accurate CNAM information for the caller. To activate email reminders, replace root in Set(email="root") in line 2 with your actual email address.

The [macro-dialout-trunk-predial-hook] context handles populating the Asterisk Phonebook WhiteList for outbound calls you make to people that are not yet in your Asterisk Phonebook. These numbers will automatically be added to your whitelist, but you also have the option of adding CNAM entries for these outbound calls using either OpenCNAM or BulkCNAM for outbound calls to numbers that are not yet in your Asterisk Phonebook. To activate CNAM lookups, simply uncomment either line 4 or 5 in the context. For the service you have activated, remember to also enter your Account SID and Auth Token in the case of OpenCNAM or your API Key in the case of BulkCNAM. If you leave both lines commented out which is the default, the callee’s phone number will be entered as both the CNAM and CNUM whitelist entry in the Asterisk Phonebook.

Once you have made all the changes desired, save the template by pressing Ctl-X, then Y, then ENTER. The installer then will complete installation of the Call Screener 2021 components.

5. Importing Previous Callers into WhiteList

We appreciate that you may not want to aggravate callers that have been calling you for years by making them jump through hoops the next time they call. So here’s a quick way to populate your Asterisk Phonebook with the names and numbers of previous callers. For entries where the CNAM is merely the CallerID Number, future calls from these numbers still will be looked up with OpenCNAM or BulkCNAM to obtain an actual CNAM match. We’ve made a couple of assumptions that you are more than welcome to adjust to meet your own needs. First, we’ve limited the list to callers from the past two calendar years. Second, we’ve only captured calls that lasted more than 15 seconds. We’ll drop down to the Linux CLI to build the list of callers to import. Then we’ll use the FreePBX GUI to import the list into the Asterisk Phonebook. While building the import list, you’ll have an opportunity to prune the list and remove any undesirable entries using nano. To generate the .csv file, issue the following commands:

cd /root
./export-CDR

Now you should have a 2YR-clean.csv file in its final form for import. Copy the file to your desktop PC and open FreePBX in your browser. Navigate to Admin -> Asterisk Phonebook. Click Import Phonebook and then Browse. Select the 2YR-clean.csv file from your desktop. Then click Upload. Take a final look at the new entries in your Asterisk Phonebook to make sure nothing came unglued, and you’re all set.


Originally published: Thursday, March 4, 2021



Need help with Asterisk? Visit the VoIP-info Forum.




Special Thanks to Our Generous Sponsors


FULL DISCLOSURE: ClearlyIP, Skyetel, Vitelity, DigitalOcean, Vultr, VoIP.ms, 3CX, Sangoma, TelecomsXchange and VitalPBX have provided financial support to Nerd Vittles and our open source projects through advertising, referral revenue, and/or merchandise. As an Amazon Associate and Best Buy Affiliate, we also earn from qualifying purchases. We’ve chosen these providers not the other way around. Our decisions are based upon their corporate reputation and the quality of their offerings and pricing. Our recommendations regarding technology are reached without regard to financial compensation except in situations in which comparable products at comparable pricing are available from multiple sources. In this limited case, we support our sponsors because our sponsors support us.

BOGO Bonaza: Enjoy state-of-the-art VoIP service with a $10 credit and half-price SIP service on up to $500 of Skyetel trunking with free number porting when you fund your Skyetel account. No limits on number of simultaneous calls. Quadruple data center redundancy. $25 monthly minimum spend required. Tutorial and sign up details are here.

The lynchpin of Incredible PBX 2020 and beyond is ClearlyIP components which bring management of FreePBX modules and SIP phone integration to a level never before available with any other Asterisk distribution. And now you can configure and reconfigure your new Incredible PBX phones from the convenience of the Incredible PBX GUI.

VitalPBX is perhaps the fastest-growing PBX offering based upon Asterisk with an installed presence in more than 100 countries worldwide. VitalPBX has generously provided a customized White Label version of Incredible PBX tailored for use with all Incredible PBX and VitalPBX custom applications. Follow this link for a free test drive!


Special Thanks to Vitelity. Vitelity is now Voyant Communications and has halted new registrations for the time being. Our special thanks to Vitelity for their unwavering financial support over many years and to the many Nerd Vittles readers who continue to enjoy the benefits of their service offerings. We will keep everyone posted on further developments.







Amazon’s Polly TTS Returns for Incredible PBX 2021




In a word, WOW! If you’ve previously used text-to-speech (TTS) applications with Incredible PBX™ or any other PBX, you fully appreciate the challenges of getting excellent voice quality from a synthesized voice. In addition to operating system quirks, you also had to scramble to find TTS software that had acceptable voice quality without breaking the bank. Well, it’s a new day with Incredible PBX 2021. Shortly after Amazon’s introduction of Polly TTS, we integrated it into the Wazo platform with Incredible PBX. However, because of Debian dependencies, we were unable to migrate it to CentOS. With RedHat’s recent decision regarding CentOS, we introduced Incredible PBX 2021 for Debian. And now is a perfect time to bring back Polly TTS as well. Polly TTS provides not only incredible voice quality but it comes at an unbelievable price point. Your first year is free for the first 5 million characters each month. After that and in subsequent years, it’s $4 for every million characters of TTS translation, and you only pay for the characters used. But, don’t take our word for it. Listen to this sample. The clip’s introduction uses the free Pico TTS voice. The Yahoo News headlines were generated with Polly. Can you say Night and Day?

[soundcloud url="https://api.soundcloud.com/tracks/319736570″ params="auto_play=false&hide_related=false&show_comments=true&show_user=true&show_reposts=false&visual=true" width="80%" height="414″ iframe="true" /]


The beauty of Nerd Vittles projects is it’s all about the freedom to choose rather than making do with choices selected by others. Today’s addition of the Polly TTS engine brings the number of TTS options supported with Incredible PBX 2021 to four. In addition to the free options of Festival and PICO, you now have two dirt cheap commercial alternatives that rival the voice quality of any available TTS application on the market. There’s IBM’s Watson which we are using for voicemail transcription. And now you have Amazon’s Polly TTS as well.




Stewart Nelson was kind enough to share his audio clip comparing the Top Four commercial TTS applications. You can judge them for yourself. The clips are played in the following order: Amazon Polly TTS, Google Translate, IBM Watson TTS, and Microsoft.

[soundcloud url="https://api.soundcloud.com/tracks/320177552″ params="auto_play=false&hide_related=false&show_comments=true&show_user=true&show_reposts=false&visual=true" width="100%" height="450″ iframe="true" /]


How New TTS Apps Will Work in Incredible PBX 2021. That’s only half of our story today. We also are introducing our proven TTS methodology that makes it easy to roll your own TTS applications and take advantage of the voice platforms already installed on your Incredible PBX 2021 server. In our new TTS design, there are three components. First, there’s a chunk of dialplan code that answers calls, prompts for input (if required), and then passes the call off for processing and generation of the TTS results using the desired TTS platform.

The processing and TTS components consist of two PHP/AGI scripts on Asterisk® servers. The results processing script actually obtains the data to feed to the TTS processing engine. For example, this could be news headlines or a local weather forecast. This script generates plain text suitable for processing by any TTS engine. Finally, a TTS script stores your user credentials (if required) and handles translation of the text results into an audio file using the TTS platform of your choice. It also plays the audio "results" to the caller. As you add new applications, all that is necessary is a short dialplan snippet and a results processing script to obtain the necessary text to feed the TTS processing script.

Here’s a sample Asterisk dialplan snippet for our Yahoo News Headlines application. Note that you need only change the pollytts line of code to switch TTS engines. Simple design!

;# // BEGIN nv-news-yahoo
exten => 951,1,Answer
exten => 951,n,Wait(1)
exten => 951,n,Set(TIMEOUT(digit)=7)
exten => 951,n,Set(TIMEOUT(response)=10)
exten => 951,n,AGI(picotts.agi,"Please hold while we get the headlines.",en-US)
exten => 951,n,AGI(nv-news-yahoo.php,10) ;  obtain latest 10 Yahoo NEWS Headlines
exten => 951,n,NoOp(News: ${NEWS}) ;  display NEWS in text format on Asterisk CLI
exten => 951,n,AGI(pollytts.php,"${NEWS}") ; pass NEWS to TTS engine for playback
exten => 951,n,Hangup
;# // END nv-news-yahoo

The picotts line (above) shows the syntax to use the Pico TTS engine instead of pollytts. The new line would look like the following. Doesn’t get much easier than this:

exten => 951,n,AGI(picotts.agi,"${NEWS}",en-US)

Getting Started. Here are the steps to get everything working with your existing Incredible PBX 2021 platform. First, you’ll need credentials from Amazon Polly after you create or sign in to your an Amazon AWS account. Enter "Polly" in the AWS dialog to add the service. Make note of your Amazon region while here. Then open your Security Credentials by clicking on your name and choosing My Security Credentials. Create a new Access Key ID and Secret. You’ll need these credentials as well as your Amazon region in a minute. Next, you’ll need to put the pieces in place on your Incredible PBX 2021 server to support Polly TTS. We’ve made this easy by bundling everything into a single tarball. Just log into your server as root, download the tarball, untar it, add MP3 support for SOX, run the included script to install the dialplan code, and edit the pollytts.php script to install your Amazon credentials. Install time: under a minute.

cd /var/lib/asterisk/agi-bin
cp -p nv-news-yahoo.php nv-news-yahoo-orig.php
cp -p nv-weather-zip.php nv-weather-zip-orig.php
wget http://incrediblepbx.com/nv-polly-install.tar.gz
tar zxvf nv-polly-install.tar.gz
rm -f nv-polly-install.tar.gz
apt-get -y install libsox-fmt-mp3
./install-polly-dialplan-incrediblepbx.sh
nano -w pollytts.php


Once the pieces are in place and the editor opens, insert your Amazon key, secret, and region code. Then save the file: Ctrl-X, Y, then ENTER.

Now you can test things out by picking up a phone connected to your PBX and dialing 951 for News or 947 for Weather by ZIP Code. Enjoy!

NEWS FLASH: This new installer works great on the Incredible PBX 2020 Raspberry Pi platform as well.



Originally published: Monday, January 22, 2021



Need help with Asterisk? Visit the VoIP-info Forum.




Special Thanks to Our Generous Sponsors


FULL DISCLOSURE: ClearlyIP, Skyetel, Vitelity, DigitalOcean, Vultr, VoIP.ms, 3CX, Sangoma, TelecomsXchange and VitalPBX have provided financial support to Nerd Vittles and our open source projects through advertising, referral revenue, and/or merchandise. As an Amazon Associate and Best Buy Affiliate, we also earn from qualifying purchases. We’ve chosen these providers not the other way around. Our decisions are based upon their corporate reputation and the quality of their offerings and pricing. Our recommendations regarding technology are reached without regard to financial compensation except in situations in which comparable products at comparable pricing are available from multiple sources. In this limited case, we support our sponsors because our sponsors support us.

BOGO Bonaza: Enjoy state-of-the-art VoIP service with a $10 credit and half-price SIP service on up to $500 of Skyetel trunking with free number porting when you fund your Skyetel account. No limits on number of simultaneous calls. Quadruple data center redundancy. $25 monthly minimum spend required. Tutorial and sign up details are here.

The lynchpin of Incredible PBX 2020 and beyond is ClearlyIP components which bring management of FreePBX modules and SIP phone integration to a level never before available with any other Asterisk distribution. And now you can configure and reconfigure your new Incredible PBX phones from the convenience of the Incredible PBX GUI.

VitalPBX is perhaps the fastest-growing PBX offering based upon Asterisk with an installed presence in more than 100 countries worldwide. VitalPBX has generously provided a customized White Label version of Incredible PBX tailored for use with all Incredible PBX and VitalPBX custom applications. Follow this link for a free test drive!


Special Thanks to Vitelity. Vitelity is now Voyant Communications and has halted new registrations for the time being. Our special thanks to Vitelity for their unwavering financial support over many years and to the many Nerd Vittles readers who continue to enjoy the benefits of their service offerings. We will keep everyone posted on further developments.




A Fresh Look at Low-Cost VoIP Cloud Providers

Now that we’re up and running in 2021 with new releases of Incredible PBX 2021 for both Debian and Ubuntu, it seemed like a fitting time to take a fresh look at VoIP cloud offerings to host your new PBX. The short story is that a cloud-based PBX is the hands-down winner over on-premise hardware these days. It’s cheaper. It’s more reliable. It’s more powerful. And it’s more flexible. The question you’re probably wanting answered is how much does it cost. The good news is it no longer will cost you an arm and a leg. In fact, it’s less expensive than the cost of electricity to run any on-premise hardware except perhaps a Raspberry Pi.

Keeping in mind the old adage that you get what you pay for, let us tick off our favorite cloud offerings together with their pricing. And, remember, you can always find a current list of recommendations on the Incredible PBX Wiki.

We like to separate cloud platforms into two main groups: those that provide periodic backups or snapshots and those that don’t. Fortunately, there are excellent backup utilities for Incredible PBX that lessen the need for provider backups, but they all entail some extra work on your part to get off-site backups configured or maintained.

Let’s begin with the elephants in the room: Amazon, Google, IBM, Microsoft, and Oracle. They all have cloud offerings, and our recommendation is don’t go there. Their services are EXPENSIVE. And they offer less functionality at significantly higher cost than some of the smaller, well-established companies such as Vultr, Digital Ocean, and OVH. If $5 to $6 a month for a cloud platform is not too rich for your blood, you can’t go wrong with any of these three. And all of them provide backups or snapshots in the pricing we’ve outlined. So they are perfect for a family or SOHO PBX. All three can also scale up to support hundreds or even thousands of users. There’s more good news. Using our referral links that support our open source projects, Vultr and Digital Ocean will give you $100 in free credits to begin your cloud journey. And, coming soon, you’ll be able to create an Incredible PBX 2021 VPS from the Vultr Marketplace in less than a minute. Here’s a sneak peek.


Also worth a careful look are a couple of other cloud providers offering either off-site backups in the case of HotLineServers at $3.80 per month or a free snapshot in the case of CrownCloud at $25 a year. CrownCloud is our personal favorite because they also offer Incredible PBX 2021 images for Debian and Ubuntu that install in a couple minutes. Simply open a ticket and ask.

If you’re just getting started with your VoIP adventure and want to keep the cost to an absolute minimum, we have a few additional recommendations, all of which we’ve tested. Keep in mind that these providers have not been in business for decades so the risk of a company failure is always there. And, yes, many have failed before. Also, none of these providers offer backups or snapshots so backups become your responsibility. But for experimentation, you can’t beat the pricing. The least costly provider is RackNerd at less than a dollar a month or $11.97 a year to be precise. This gets you a KVM platform with 1GB of RAM, 17GB of SSD storage, and 3TB of monthly bandwidth. And it’s screaming fast clocking in with 900+ Mbit/second downloads AND uploads on their Atlanta node. There are a few other low-cost providers that are worth a careful look. See the Incredible PBX Wiki for current options.

Finally, a word about backups. Moving from one VPS provider to another can be a painful experience. Typically, the Incredible Backup and Restore route is not your best bet because of possible differences in VPS design. This becomes even more tedious if you elect to switch operating systems, for example moving from CentOS to Debian or Ubuntu. Our recommendation is to stick with a FreePBX® backup in these situations. The FreePBX Wiki will walk you through the setup process. What that means is that, if your server fails or you wish to switch VPS platforms, you then would create a new VPS on the new platform using the traditional Incredible PBX installer. Once it is fully operational, you then can restore your FreePBX backup from the old platform.



Originally published: Monday, February 8, 2021



Need help with Asterisk? Visit the VoIP-info Forum.




Special Thanks to Our Generous Sponsors


FULL DISCLOSURE: ClearlyIP, Skyetel, Vitelity, DigitalOcean, Vultr, VoIP.ms, 3CX, Sangoma, TelecomsXchange and VitalPBX have provided financial support to Nerd Vittles and our open source projects through advertising, referral revenue, and/or merchandise. As an Amazon Associate and Best Buy Affiliate, we also earn from qualifying purchases. We’ve chosen these providers not the other way around. Our decisions are based upon their corporate reputation and the quality of their offerings and pricing. Our recommendations regarding technology are reached without regard to financial compensation except in situations in which comparable products at comparable pricing are available from multiple sources. In this limited case, we support our sponsors because our sponsors support us.

BOGO Bonaza: Enjoy state-of-the-art VoIP service with a $10 credit and half-price SIP service on up to $500 of Skyetel trunking with free number porting when you fund your Skyetel account. No limits on number of simultaneous calls. Quadruple data center redundancy. $25 monthly minimum spend required. Tutorial and sign up details are here.

The lynchpin of Incredible PBX 2020 and beyond is ClearlyIP components which bring management of FreePBX modules and SIP phone integration to a level never before available with any other Asterisk distribution. And now you can configure and reconfigure your new Incredible PBX phones from the convenience of the Incredible PBX GUI.

VitalPBX is perhaps the fastest-growing PBX offering based upon Asterisk with an installed presence in more than 100 countries worldwide. VitalPBX has generously provided a customized White Label version of Incredible PBX tailored for use with all Incredible PBX and VitalPBX custom applications. Follow this link for a free test drive!


Special Thanks to Vitelity. Vitelity is now Voyant Communications and has halted new registrations for the time being. Our special thanks to Vitelity for their unwavering financial support over many years and to the many Nerd Vittles readers who continue to enjoy the benefits of their service offerings. We will keep everyone posted on further developments.




A New Day: Introducing Incredible PBX 2021 for Ubuntu 20.04

We’ve completed the rollout of Incredible PBX 2021 for Debian 10 and, thanks to the terrific work of @jaminmc, today we’re pleased to introduce Incredible PBX 2021 for Ubuntu 20.04 LTS with its ten-year life cycle.

In addition to @jaminmc, we also want to offer our special thanks to the many talented individuals on the VoIP-Info.org Forum who work through the growing pains of these new releases to bring you open source products at zero cost. Come join the party!

If you’re using on-premise hardware, begin by downloading the ISO image of Ubuntu 20.04 for amd64. Follow our previous tutorials for tips on installation with VirtualBox or VMware ESXi. If you’d prefer to experiment in the cloud for about a penny an hour, open an account at Vultr or Digital Ocean using our referral links that support the Nerd Vittles project. You’ll also get some free credit to try out the service. Then create a new $5/month Ubuntu 20.04, 64-bit instance in your favorite city. Want some cheaper KVM cloud alternatives? Visit the Incredible PBX Wiki.

If your PBX is sitting behind a NAT-based router, you’ll need to redirect incoming UDP 5060-5061 and UDP 10000-20000 traffic to the private IP address of your server. This is required for all of the SIP providers included in the Incredible PBX 2021 build. Otherwise, all inbound calls will fail.

Installing Incredible PBX 2021 on Ubuntu 20.04 Server

Once your Ubuntu 20.04 platform is up and running, login as root using SSH or Putty. If you wish to use the default Asterisk 18 platform, issue the commands below to kick off the install. If you’d prefer to stick with Asterisk 16 for the time being and perhaps upgrade to Asterisk 18 later with the included upgrade script, then edit the script once you download it and change 18 to 16 in line 34 of the script before executing it.

wget http://incrediblepbx.com/IncrediblePBX2021-U.sh
chmod +x IncrediblePBX2021-U.sh
./IncrediblePBX2021-U.sh

At about 5 minutes into the install procedure, you’ll be prompted for your telephone country code. It’s 1 for Canada and the United States. Once the installation completes, reboot and you should be good to go.

Next Steps with Incredible PBX 2021

Before you can manage your PBX through a web browser, you first will need to set the admin passwords for FreePBX, Apache web apps such as Reminders and AsteriDex, and AvantFax (if you are using Incredible Fax). These all can be set by logging into your server as root and issuing the following commands: admin-pw-change, apache-pw-change, and avantfax-pw-change. The AvantFax password can also be reset with a browser by first logging in as admin with a password of password.

Outbound mail functionality needs to be working so that you can receive voicemail messages and faxes by email. To prevent SPAM, most ISPs and ITSPs block messages from downstream mail servers. That would be you. The easiest way to resolve this is to configure SendMail using Gmail as an SMTP Smarthost. You obviously need a Gmail account to implement this and, if you have turned on two-factor authentication for your Gmail account, you also will need to obtain an App password for your Gmail account, and use that in lieu of your regular Gmail password when configuring SendMail. With your Gmail username and password in hand, log into your server as root and run: /root/enable-gmail-smarthost-for-sendmail.

If your Incredible PBX 2021 is hosted with a cloud provider, be advised that many providers do not include a swap file as part of their offering. FreePBX requires a swap file. To add one, issue this command after logging into your server as root: /root/create-swapfile-DO.

To correctly set the time on your PBX, run: /root/timezone-setup.

By default, the voicemail password for each of the configured extensions (701-705) is set to the extension number. This means the user will be prompted to set a voicemail password on the first login to voicemail for each extension. A phone must be registered to the actual extension to access its voicemail account. For example, once a phone is registered to extension 701, the voicemail setup can be accessed by dialing *98701.

If you want to send and receive faxes with Incredible PBX 2021, download the new Incredible Fax 2021 for Ubuntu script, make it executable (chmod +x incred*), and then run the following script while logged into your server as root: /root/incrediblefax2021-ubuntu20.04.sh. When prompted, accept all the defaults. Once the HylaFax and AvantFax components are installed, reboot your server. To send faxes, click on the AvantFax tab in the FreePBX GUI and enter your login credentials (default: admin/password). To receive incoming faxes once you have configured a trunk and DID for your PBX, login to the FreePBX GUI as admin. Navigate to Connectivity -> Inbound Routes. For each of your DIDs on which you wish to receive faxes, select the inbound route and click the Fax tab. Review the Default Inbound Route Fax settings for proper setup.

Overview of the Initial Asterisk Setup Process

For those new to PBXs, here’s a two paragraph summary of how Voice over IP (VoIP) works. Phones connected to your PBX are registered with Extensions so that they can make and receive calls. When a PBX user picks up a phone and dials a number, an Outbound Route tells the PBX which Trunk to use to place the call based upon established dialing rules. Unless the dialed number is a local extension, a Trunk registered with some service provider accepts the call, and the PBX sends the call to that provider. The provider then routes the call to its destination where the recipient’s phone rings to announce the incoming call. When the recipient picks up the phone, the conversation begins.

Looking at things from the other end, when a caller somewhere in the world wishes to reach you, the caller picks up a telephone and dials a number known as a DID that is assigned to you by a provider with whom you have established service. When the provider receives the call to your DID, it routes the call to your PBX based upon destination information you established with the provider. Your PBX receives the call with information identifying the DID of the call as well as the CallerID name and number of the caller. An Inbound Route on your PBX then determines where to send the call based upon that DID and CallerID information. Typically, a call is routed to an Extension, a group of Extensions known as a Ring Group, or an IVR or AutoAttendant giving the caller choices on routing the call to the desired destination. Once the call is routed to an Extension, the PBX rings the phone registered to that Extension. When you pick up the phone, the conversation begins.

Configuring Trunks with Incredible PBX GUI

Perhaps the most difficult component to configure in the PBX is the Trunk. Almost every provider has a different way of doing things. We’ve taken some of the torture out of the exercise by providing a script which will configure settings for dozens of providers in seconds. Once installed, all you need to do is edit the desired Trunk (Connectivity:Trunks), change the Disable Trunk entry to No, and insert your credentials in both the PEER Details and Registration string of the SIP Settings Outgoing and Incoming tabs. Skyetel is enabled by default and needs no setup on the PBX side.

Configuring Skyetel for Incredible PBX 2021

If you’ve decided to go with Skyetel, here’s the drill. Sign up for Skyetel service and take advantage of the Nerd Vittles specials. First, complete the Prequalification Form here. You then will be provided a link to the Skyetel site to complete your registration. Once you have registered on the Skyetel site and your account has been activated, open a support ticket and request the $10 credit for your account by referencing the Nerd Vittles special offer. Once you are satisfied with the service, fund your account as desired, and Skyetel will match your deposit of up to $250 simply by opening another ticket. That gets you up to $500 of half-price calling. Credit is limited to one per person/company/address/location. Effective 10/1/2023, $25/month minimum spend required.

Skyetel does not use SIP registrations to make connections to your PBX. Instead, Skyetel utilizes Endpoint Groups to identify which servers can communicate with the Skyetel service. An Endpoint Group consists of a Name, an IP address, a UDP or TCP port for the connection, and a numerical Priority for the group. For incoming calls destined to your PBX, DIDs are associated with an Endpoint Group to route the calls to your PBX. For outgoing calls from your PBX, a matching Endpoint Group is required to authorize outbound calls through the Skyetel network. Thus, the first step in configuring the Skyetel side for use with your PBX is to set up an Endpoint Group. Here’s a typical setup for Incredible PBX 2021:

  • Name: MyPBX
  • Priority: 1
  • IP Address: PBX-Public-IP-Address
  • Port: 5060
  • Protocol: UDP
  • Description: my.incrediblepbx.com

To receive incoming PSTN calls, you’ll need at least one DID. On the Skyetel site, you acquire DIDs under the Phone Numbers tab. You have the option of Porting in Existing Numbers (free for the first 60 days after you sign up for service) or purchasing new ones under the Buy Phone Numbers menu option.

Once you have acquired one or more DIDs, navigate to the Local Numbers or Toll Free Numbers tab and specify the desired SIP Format and Endpoint Group for each DID. Add SMS/MMS and E911 support, if desired. Call Forwarding and Failover are also supported. That completes the VoIP setup on the Skyetel side. System Status is always available here.

Configuring VoIP.ms for Incredible PBX 2021

To sign up for VoIP.ms service, may we suggest you use our signup link so that Nerd Vittles gets a referral credit for your signup. Once your account is set up, you’ll need to set up a SIP SubAccount and, for Authentication Type, choose Static IP Authentication and enter your Incredible PBX 2021 server’s public IP address. For Transport, choose UDP. For Device Type, choose Asterisk, IP PBX, Gateway or VoIP Switch. Order a DID in their web panel, and then point the DID to the SubAccount you just created. Be sure to specify atlanta1.voip.ms as the POP from which to receive incoming calls. In the Incredible PBX GUI, be sure to enable the VoIP.ms trunk.

Configuring V1VoIP for Incredible PBX 2021

To sign up for V1VoIP service, sign up on their web site. Then login to your account and order a DID under the DIDs tab. Once the DID has been assigned, choose View DIDs and click on the Forwarding button beside your DID. For Option #1, choose Forward to IP Address/PBX. For the Forwarding Address, enter the public IP address of your server. For the T/O (timeout) value, set it to 2o seconds. Then click the Update button. Under the Termination tab, create a new Endpoint with the public IP address of your server so that you can place outbound calls through V1VoIP. In the Incredible PBX GUI, be sure to enable all of the V1VoIP trunks.

Configuring Anveo Direct for Incredible PBX 2021

To sign up for Anveo Direct service, sign up on their web site and then login. After adding funds to your account, purchase a DID under Inbound Service -> Order DID. Next, choose Configure Destination SIP Trunk. Give the Trunk a name. For the Primary SIP URI, enter $[E164]$@server-IP-address. For Call Options, select your new DID from the list. You also must whitelist your public IP address under Outbound Service -> Configure. Create a new Call Termination Trunk and name it to match your server. For Dialing Prefix, choose six alphanumeric characters beginning with a zero. In Authorized IP Addresses, enter the public IP address of your server. Set an appropriate rate cap. We like $0.01 per minute to be safe. Set a concurrent calls limit. We like 2. For the Call Routing Method, choose Least Cost unless you’re feeling extravagant. For Routes/Carriers, choose Standard Routes. Write down your Dialing Prefix and then click the Save button.

Before you can make outbound calls through Anveo Direct from your PBX, you first must configure the Dialing Prefix that you wrote down in the previous step. Log into the GUI as admin using a web browser and edit the Anveo-Out trunk in Connectivity -> Trunks. Enable the Trunk. Then click on the custom-Settings tab and replace anveo-pin with your actual Dialing Prefix. Click Submit and Apply Config to complete the setup. In the Incredible PBX GUI, be sure to enable all of the remaining Anveo trunks.

By default, incoming Anveo Direct calls will be processed by the Default inbound route on your PBX. If you wish to redirect incoming Anveo Direct calls using DID-specific inbound routes, then you’ve got a bit more work to do. In addition to creating the inbound route using the 11-digit Anveo Direct DID, enter the following commands after logging into your server as root using SSH/Putty:

cd /etc/asterisk
echo "[from-anveo]" >> extensions_custom.conf
echo "exten => _.,1,Ringing" >> extensions_custom.conf
echo "exten => _.,n,Goto(from-trunk,\\${SIP_HEADER(X-anveo-e164)},1)" >> extensions_custom.conf
asterisk -rx "dialplan reload"

Configuring Extensions with Incredible PBX GUI

Extensions are created using the Incredible PBX GUI: Applications:Extensions. Many SIP phones expect extensions to communicate on UDP port 5060. If this is the case with your SIP phone or softphone, then always create Chan_SIP extensions which communicate on UDP 5060. If your SIP phone or softphone provide port flexibility, then you have a choice in the type of SIP extension to create: Chan_SIP or the more versatile PJSIP (UDP 5061). Just remember to always configure SIP extensions with NAT Mode=YES in the Advanced tab. If your VoIP phones or softphones support IAX connectivity, you may wish to consider IAX extensions which avoid NAT problems.

When you create a new Extension, a new entry is automatically created in the PBX Internal Directory. If you wish to allow individual users to manage their extensions or use the WebRTC softphone, then you will also have to create a (very) secure password for User Control Panel (UCP) access. Choose Admin:User Management and click on the key icon of the desired extension to assign a password for UCP and WebRTC access.

Configuring a Desktop Softphone for Incredible PBX

We’re in the home stretch now. You can connect virtually any kind of telephone to your new PBX. Plain Old Phones require an analog telephone adapter (ATA) which can be a separate board in your computer from a company such as Digium. Or it can be a standalone SIP device such as ObiHai’s OBi100 or OBi110 (if you have a phone line from Ma Bell to hook up as well). SIP phones can be connected directly so long as they have an IP address. These could be hardware devices or software devices such as the YateClient softphone. We’ll start with a free one today so you can begin making calls. You can find dozens of recommendations for hardware-based SIP phones both on Nerd Vittles and the PIAF Forum when you’re ready to get serious about VoIP telephony.

We recommend YateClient for Windows which is free. Download it from here. Run YateClient once you’ve installed it and enter the credentials for the 701 extension on Incredible PBX. You can find them by running /root/show-passwords. You’ll need the IP address of your server plus your extension 701 password. In the YateClient, fill in the blanks using the IP address of your Server, 701 for your Username, and whatever Password was assigned to the extension when you installed Incredible PBX. Click OK to save your entries.

Once you are registered to extension 701, close the Account window. Then click on YATE’s Telephony Tab and place some test calls to the numerous apps that are preconfigured on Incredible PBX. Dial a few of these to get started:

DEMO - Apps Demo
123 - Reminders
947 - Weather by ZIP Code
951 - Yahoo News
TODAY - Today in History
LENNY - The Telemarketer's Worst Nightmare

If you are a Mac user, another great no-frills softphone is Telephone. Just download and install it from the Mac App Store. For Android users, check out the terrific new VitalPBX Communicator. Works flawlessly with Incredible PBX.

Configuring a Softphone Extension on a Smartphone

Adding an Incredible PBX extension to your smartphone gets a little trickier. Whether you’re an iPhone or Android lover, all smartphones use batteries, and you don’t want to drain your battery by running a softphone as a foreground app all the time. Fortunately, you now have some choices in softphones engineered to work without draining your battery. While they all cost money, it’s not much money. We’ve written about all the choices, and you’ll find the links in our Softphone Provider Recommendations on the new Incredible PBX Wiki.

With PJsip extensions, you’re not limited to a single phone connection at a time, and we’ve preconfigured extension 701 to support five simultaneous connections. The setup on the softphone side is simple. For the server, enter the actual IP address of your PBX in the following format: 22.33.44.55:5061. Then enter 701 for the username and enter the password assigned to the 701 extension on your PBX. When an incoming call arrives, all the phones registered to extension 701 will ring simultaneously. Simply answer the call on the phone that is most convenient.

Configuring Outbound Routes in Incredible PBX GUI

Outbound Routes serve a couple of purposes. First, they assure that calls placed by users of your PBX are routed out through an appropriate trunk to reach their destination in the least costly manner. Second, they serve as a security mechanism by either blocking or restricting certain calls by requiring a PIN to complete the calls. Never authorize recurring charges on credit cards registered with your VoIP providers and, if possible, place pricing limits on calls with your providers. If a bad guy were to break into your PBX, you don’t want to give the intruder a blank check to make unauthorized calls. And you certainly don’t want to join the $100,000 Phone Bill Club.

To create outbound routes in the Incredible PBX GUI, navigate to Connectivity:Outbound Routes and click Add Outbound Route. In the Route Settings tab, give the Outbound Route a name and choose one or more trunks to use for the outbound calls. In the Dial Patterns tab, specify the dial strings that must be matched to use this Outbound Route. NXXNXXXXXX would require only 10-digit numbers with the first and fourth digits being a number between 2 and 9. Note that Outbound Routes are searched from the top entry to the bottom until there is a match. Make certain that you order your routes correctly and then place test calls watching the Asterisk CLI to make sure the calls are routed as you intended.

Configuring Inbound Routes in Incredible PBX GUI

Inbound Routes, as the name implies, are used to direct incoming calls to a specific destination. That destination could be an extension, a ring group, an IVR or AutoAttendant, or even a conference or DISA extension to place outbound calls (hopefully with a very secure password). Inbound Routes can be identified by DID, CallerID number, or both. To create Inbound Routes, choose Connectivity:Inbound Routes and then click Add Inbound Route. Provide at least a Description for the route, a DID to be matched, and the Destination for the incoming calls that match. If you only want certain callers to be able to reach certain extensions, add a CallerID number to your matching criteria. You can add Call Recording and CallerID CNAM Lookups under the Other tab.

Audio Issues with Incredible PBX 2021

If you experience one-way or no audio on some calls, add your external IP address and LAN subnet in the GUI by navigating to Settings -> Asterisk SIP Settings. In the NAT Settings section, click Detect Network Settings. Click Submit and Apply Settings to save your changes.

Security Considerations with Incredible PBX 2021

Incredible PBX 2021 includes a rock-solid firewall that limits access to preferred providers and individuals whose IP addresses you have whitelisted. Unfortunately, this may not insulate your server from FreePBX 15 irregularities if, in fact, Sangoma’s signing key was compromised in the October 2020 Ransomware Attack. Sangoma either doesn’t know or isn’t telling. Keep in mind that Sangoma didn’t mention the October breach either until someone else exposed it. Sangoma’s latest press release is available here.

The good news is Incredible PBX 2020 and 2021 platforms include a unique ClearlyIP feature that lets us manage which modules and versions can be installed. It works exactly like what ClearlyIP has documented in their must-read blog post, and we’ve built a locked version that rolls back all of the modules to dates before the Sangoma breach. The good news is, with Incredible PBX, you don’t have to jump through all the hoops covered in the ClearlyIP article to fully insulate your server from the Ransomware breach. We’ve done the work for you.

For those with mission-critical platforms, we’d recommend immediate implementation of what follows. For everyone else, it’s your choice whether to wait and see if there is a breach of the signing certificate with malicious modules. If you opt to wait and see, MAKE FREQUENT BACKUPS.

Here’s how to roll back all of your modules to dates before the breach. Login to the FreePBX GUI as admin and navigate to Settings > Advanced Settings. Drop down to the Lock Version field and change 15.19.11.001 to 15.19.11.003. Save your changes and reload your dialplan. Then use Module Admin to roll back any installed modules that are newer than the safe versions shown.

Our extra special thanks goes to Tony Lewis and the ClearlyIP team for providing this invaluable resource. Somehow we knew it would come in handy sooner or later. Unfortunately, that day has come.

Adding Incredible PBX 2021 to an OpenVPN Network

We previously have documented the procedure for creating an OpenVPN server as well as OpenVPN client templates (.ovpn). If you need a refresher, the tutorial is here. To add your Incredible PBX 2021 server to an existing OpenVPN network, begin by creating an incrediblepbx2021.ovpn template on your OpenVPN server. Be sure to comment out or delete the setenv line in the template. Then copy this template to /etc on your Incredible PBX 2021 server. Next, issue the following commands to put the remaining pieces in place:

cp -p /root/openvpn-start /etc/.
echo "[Unit]
Description=openvpn2021
ConditionPathExists=/etc/openvpn-start
After=rclocal.service
[Service]
Type=forking
ExecStart=/etc/openvpn-start /etc/incrediblepbx2021.ovpn
TimeoutSec=0
StandardOutput=tty
RemainAfterExit=yes
PermissionsStartOnly=true
SysVStartPriority=99
[Install]
WantedBy=multi-user.target" > /etc/systemd/system/openvpn2021.service

Finally, enable the new openvpn2021.service and reboot your server. The OpenVPN IP address should now appear on the LAN line in pbxstatus:

systemctl enable openvpn2021.service
reboot

Incredible PBX 2021 Administration

We’ve eased the pain of administering your new PBX with a collection of scripts which you will find in the /root folder after logging in with SSH or Putty. Here’s a quick summary of what each of the scripts does.

add-fqdn is used to whitelist a fully-qualified domain name in the firewall. Because Incredible PBX 2021 blocks all traffic from IP addresses that are not whitelisted, this is what you use to authorize an external user for your PBX. The advantage of an FQDN is that you can use a dynamic DNS service to automatically update the IP address associated with an FQDN so that you never lose connectivity.

add-ip is used to whitelist a public IP address in the firewall. See the add-fqdn explanation as to why this matters.

del-acct is used to remove an IP address or FQDN from the firewall’s whitelist.

admin-pw-change is used to set the admin password for access to the FreePBX/Incredible PBX web GUI using a browser pointed to the local IP address of your server.

apache-pw-change is used to set the admin password for access to Apache/Incredible PBX apps including AsteriDex and Reminders. This provides a password layer of protection for access to these applications.

avantfax-email-change is used to change the destination email address for incoming faxes.

avantfax-pw-change is used to change your admin password for the AvantFax web console.

iaxmodem-restart is used to restart the modems used to send and deliver faxes. The pbxstatus display will tell you whether the IAXmodems are down.

incrediblebackup2021 makes a backup of critical components on your PBX to a tarball saved in /backup. This should be copied to safe location off-site for a rainy day.

incrediblerestore2021 restores a backup file which has been copied to the /backup folder.

ipchecker is a script which deciphers the public IP addresses associated with whitelisted FQDNs created with add-fqdn on your server. If any of the addresses have changed, the firewall is restarted after updating the IP addresses. By default, it is executed every 10 minutes by /etc/crontab.

licenses.sh displays the license associated with each of the FreePBX modules on your server.

logos-b-gone removes proprietary artwork from your PBX and is no longer necessary with the included IncrediblePBX FreePBX module.

mime-construct is a command-line utility to send emails with attachments.

neorouter-login is a script to add your PBX to a NeoRouter VPN. Tutorial here.

odbc-gen.sh is a script that was run to generate the ODBC settings for Asterisk. Do NOT use it.

openvpn-start is a script to add your PBX to an existing OpenVPN network using an .ovpn config file. Tutorial here.

pbxstatus displays status of all major components of Incredible PBX 2021.

pptp-install is a script to create a PPTP network connection for your PBX. Tutorial here.

purge-cdr-cel-records removes all CDR and CEL records from the MySQL database.

reset-conference-pins is a script that automatically and randomly resets the user and admin pins for access to the preconfigured conferencing application. Dial C-O-N-F from any registered SIP phone to connect to the conference.

reset-extension-passwords is a script that automatically and randomly resets ALL of the SIP passwords for extensions 701-705. Be careful using this one, or you may disable existing registered phones and cause Fail2Ban to blacklist the IP addresses of those users. HINT: You can place a call to the Ring Group associated with all five extensions by dialing 777.

reset-reminders-pin is a script that automatically and randomly resets the pin required to access the Telephone Reminders application by dialing 123. It’s important to protect this application because a nefarious user could set up a reminder to call a number anywhere in the world assuming your SIP provider’s account was configured to allow such calls.

show-feature-codes is a cheat sheet for all of the feature codes which can be dialed from any registered SIP phone. It documents how powerful a platform Incredible PBX 2021 actually is. A similar listing is available in the GUI at Admin -> Feature Codes.

show-passwords is a script that displays most of the passwords associated with Incredible PBX 2021. This includes SIP extension passwords, voicemail pins, conference pins, telephone reminders pin, and your Anveo Direct outbound calling pin (if configured). Note that voicemail pins are configured by the user of a SIP extension the first time the user accesses the voicemail system by dialing *97.

sig-fix disables Module Signature Checking in the FreePBX GUI. This should not be necessary unless you have added or edited FreePBX Modules with missing module signatures.

sms-skyetel is a script to send SMS messages using a Skyetel trunk.

sms-voip.ms is a script to send SMS messages using a VoIP.ms trunk.

sms-blast, sms-blaster, and sms-dictator are scripts for message blasting. Tutorial here.

switch-to-php5.6 is a script to disable PHP 7.3 and set PHP 5.6 as the default version for your PBX. PHP 5.6 is required to use AvantFax. It is the default configuration for Incredible PBX 2021. The current default PHP version is displayed in the Apache listing of pbxstatus.

switch-to-php7.3 is a script to disable PHP 5.6 and set PHP 7.3 as the default version for your PBX. You cannot use AvantFax when PHP 7.3 is the default.

timezone-setup is a script to set the timezone for your PBX.

update-IncrediblePBX is a script that runs the Automatic Update Utility whenever you login to your server as root. These updates typically resolve bugs and security issues with your PBX. Do NOT remove it.

upgrade-asterisk16 is a script that runs on Asterisk 16 platforms to upgrade your PBX to the latest release of Asterisk 16.

upgrade-asterisk18 is a script that runs on both Asterisk 16 and 18 platforms to upgrade your PBX to the latest release of Asterisk 18.

wolfram is a script to deploy Wolfram Alpha on your PBX. Tutorial here.

Forwarding Calls to Your Cellphone. Keep in mind that inbound calls to your DIDs automatically ring all five SIP extensions, 701-705. The easiest way to also ring your cellphone is to set one of these five extensions to forward incoming calls to your cellphone. After logging into your PBX as root, issue the following command to forward calls from extension 705 to your cellphone: asterisk -rx "database put CF 705 6781234567"

To remove call forwarding: asterisk -rx "database del CF 705"

Keeping FreePBX 15 Modules Current

We strongly recommend that you periodically update all of your FreePBX modules to eliminate bugs and to reduce security vulnerabilities. From the Linux CLI, log into your server as root and issue the following commands:

rm -f /tmp/*
fwconsole ma upgradeall
fwconsole reload
/root/sig-fix
systemctl restart apache2
/root/sig-fix



Originally published: Tuesday, January 26, 2021



Need help with Asterisk? Visit the VoIP-info Forum.




Special Thanks to Our Generous Sponsors


FULL DISCLOSURE: ClearlyIP, Skyetel, Vitelity, DigitalOcean, Vultr, VoIP.ms, 3CX, Sangoma, TelecomsXchange and VitalPBX have provided financial support to Nerd Vittles and our open source projects through advertising, referral revenue, and/or merchandise. As an Amazon Associate and Best Buy Affiliate, we also earn from qualifying purchases. We’ve chosen these providers not the other way around. Our decisions are based upon their corporate reputation and the quality of their offerings and pricing. Our recommendations regarding technology are reached without regard to financial compensation except in situations in which comparable products at comparable pricing are available from multiple sources. In this limited case, we support our sponsors because our sponsors support us.

BOGO Bonaza: Enjoy state-of-the-art VoIP service with a $10 credit and half-price SIP service on up to $500 of Skyetel trunking with free number porting when you fund your Skyetel account. No limits on number of simultaneous calls. Quadruple data center redundancy. $25 monthly minimum spend required. Tutorial and sign up details are here.

The lynchpin of Incredible PBX 2020 and beyond is ClearlyIP components which bring management of FreePBX modules and SIP phone integration to a level never before available with any other Asterisk distribution. And now you can configure and reconfigure your new Incredible PBX phones from the convenience of the Incredible PBX GUI.

VitalPBX is perhaps the fastest-growing PBX offering based upon Asterisk with an installed presence in more than 100 countries worldwide. VitalPBX has generously provided a customized White Label version of Incredible PBX tailored for use with all Incredible PBX and VitalPBX custom applications. Follow this link for a free test drive!


Special Thanks to Vitelity. Vitelity is now Voyant Communications and has halted new registrations for the time being. Our special thanks to Vitelity for their unwavering financial support over many years and to the many Nerd Vittles readers who continue to enjoy the benefits of their service offerings. We will keep everyone posted on further developments.
