In our last article, we documented how to implement free, safe SIP URI worldwide calling with an almost-free Issabel™ server in the Cloud. Today we’ll add another free worldwide calling option using iNum™. As with SIP URIs, iNum provides a way for anyone in the world to reach you by phone without paying a nickel. And iNum adds the same functionality for Issabel PBX users to reach anyone else in the world with an iNum phone number. The iNum project was started almost a decade ago by Voxbone to create a free global phone network for IP communications. The International Telecommunication Union allocated a portion of its non-geographic country code +883 to the initiative. iNums are 15-digit telephone numbers in the +883 5100 area code. You can keep yours for life at no cost.
Let’s begin by obtaining an iNum telephone number for your Issabel PBX. Every PBX should have at least one. There are a number of iNum providers throughout the world that will give you an iNum telephone number at no cost. For our purposes today, we’ll document the procedure for CallCentric. Assuming you have 911 service with another provider, it won’t cost you anything to set up a CallCentric account and obtain a working iNum telephone number. Other providers (e.g. LocalPhone) typically require a modest deposit just to set up an account which is perfectly understandable. However, CallCentric doesn’t require a credit card up front. If you already have a VoIP.ms account from our tutorial last week, they also offer free iNum phone numbers: Order DIDs:iNum (limited to one per account).
Obtaining an iNum Phone Number from CallCentric
Navigate to the CallCentric web site and click Sign Up. Once your account is activated, login using your new credentials. Jot down your Username, CallCentric #, and Password for future access to the web site. From the main Dashboard, click View/Modify Extensions. Extension 100 should already be set up. Just create a SIP password and jot it down with your SIP username which is the same as your CallCentric #. Click Apply and then SAVE.
Next, let’s order the CallCentric freebies which include BOTH an iNum phone number and a traditional DID. Neither one costs you money, but you do have to use the DID once a month to keep it. The iNum phone number never expires. Under Products, click Order. Under Make Calls, choose the IP Freedom Plan unless you want to use CallCentric to make commercial calls. Under Receive Calls, choose Free Phone Number and Get a Number. Write down your 10-digit number. To obtain an iNum phone number, click here and then click Order an iNum Number. Write down your iNum phone number. UPDATE: CallCentric now will let you order multiple iNum phone numbers at no cost. Each supports two simultaneous calls and unlimited incoming minutes.
With CallCentric, you have two options in routing incoming calls. You can use the Default routing setup which will send the calls to your CallCentric registered trunk (which we will set up below) on your Issabel PBX. Or you can customize the routing and forward the calls for each DID and iNum number to a SIP URI. From the Dashboard, choose Phone Number Forwarding. If you simply want to forward both your DID and iNum numbers to the SIP URI that you set up last week with VoIP.ms, then no trunk registration (below) is required at all. However, you would lose the ability to use CallCentric to place outbound iNum calls from your Issabel extensions.
Integrating iNum Support into Your Issabel PBX
In the Issabel web GUI, we need to configure the trunk for CallCentric. The template already is included with Incredible PBX® for Issabel. Then we need to set up an Inbound Route for CallCentric as well as an outbound route to process iNum calls originating from Issabel extensions.
To configure the CallCentric trunk, navigate to PBX:PBX Config:Trunks:CallCentric. First, uncheck the Disable Trunk field. In Outgoing Settings, insert your SIP username (1777XXXXXXX) in the fromuser and defaultuser fields as well as in the initial field (before colon) and last field (after /) of the Registration String. Insert your SIP password in the secret field and the second field (after the colon) in the Registration String. Submit Changes and Reload Dialplan when prompted.
Next create an Outbound Route for iNum calls using your CallCentric trunk. Navigate to PBX:PBX Config:Outbound Routes. Click Add Route. For Route Name, use Out-CallCentric-iNum. For Dial Pattern, insert 008835100 in the Prepend field and XXXXXXXX in the Match Pattern field. For Trunk Sequence, choose CallCentric. Click Submit Changes and Reload Dialplan when prompted.
Next create an Inbound Route for calls coming from your CallCentric trunk. This will include BOTH your iNum calls and calls from your free CallCentric DID. Navigate to PBX:PBX Config:Inbound Routes. Click Add Incoming Route. For Description, use CallCentric-Incoming. For DID Number, use your SIP username (1777XXXXXXX). For CID Lookup Source, choose OpenCNAM. Then pick a Destination for the incoming calls, e.g. an extension, ring group, or IVR. Click Submit Changes and Reload Dialplan when prompted.
Placing iNum Calls from Issabel Extensions
With our simplified outbound route, users of Issabel extensions can dial iNum phone numbers by simply dialing the last 8 digits of the number, i.e. all of the numbers following 8835100. Most abbreviated numbers start with a zero. For example, to reach Lenny, simply dial 01198938.
Placing iNum Calls from SIP Phones
If you want to reach an iNum number and only have a SIP phone, you can dial any iNum phone number in SIP URI format. Use this syntax: sip:8835100xxxxxxxx@sip.inum.net. Note that the full iNum phone number is required.
Placing iNum Calls from Standard Phones
As part of the iNum initiative, local access numbers have been established in more than 50 countries around the globe. By placing a local call from any telephone to one of these local access numbers, any individual with an iNum phone number anywhere in the world can be reached without further cost. Here is a current list of the local access numbers. Once your call is answered, simply enter the 15-digit iNum phone number you wish to reach, and you will be connected. Here is the latest iNUM listing from DSL Reports:
Country City Access Number ------------------- ------------------------ --------------- Argentina Buenos Aires +54 1159839500 Australia Sydney +61 280148200 Austria +43 720880500 Bahrain +973 16199200 Belgium Brussels +32 28081771 Brazil Brasilia +556135500791 Brazil Florianopolis +554840420809 Brazil Rio De Janeiro +552135006959 Brazil Sao Paulo +551146803621 Bulgaria Sofia +359 24917555 Canada Calgary (403) 775-1446 Canada Edmonton (780) 669-9257 Canada Halifax (902) 982-6937 Canada London (519) 488-9336 Canada Montreal (514) 907-7500 Canada Ottawa (613) 686-4519 Canada Quebec City (418) 800-0384 Canada St. Johns, Newfoundland (709) 757-0060 Canada Regina (306) 988-1600 Canada Toronto (416) 800-4303 Canada Toronto (647) 724-8777 Canada Vancouver (778) 786-3497 Canada Winnipeg (204) 272-8182 Chile Santiago +56 25813444 Croatia Zagreb +385 17776363 Cyprus Nicosia +357 22030500 Czech Republic Prague +420 246019777 Denmark +45 69918686 Dominican Republic Santiago (829) 947-9610 El Salvador +503 21131899 Estonia +372 6681881 Finland Helsinki +358 942419200 France Paris +33 170619800 Germany Frankfurt +4969257385876 Germany Frankfurt +4969257380439 Greece Athens +30 2111768444 Hungary Budapest +36 14088951 Ireland Dublin +353 15262600 Israel Tel Aviv +972 37219555 Italy Rome +39 0662207777 Japan Tokyo +81 345209777 Latvia Vilnius +370 52059090 Lithuania +371 67652500 Luxembourg +352 20880108 Malta +35627780107 Mexico Guadalajara +52 3346242977 Mexico Mexico City +52 5511678222 Mexico Monterrey +52 8141703540 Netherlands Amsterdam +31 208080808 New Zealand Auckland +64 99250499 Norway Oslo +47 21031306 Panama +507 8322488 Peru Lima +51 17085500 Poland Warsaw +48 223982688 Portugal Lisbon +351 308803219 Puerto Rico Bayamon Norte (787) 395-7140 Romania +40 318103500 Singapore +65 31581212 Slovakia Bratislava +421 233002555 Slovenia Ljubljana +386 16001422 South Africa Johannesburg +27105002854 South Africa Pretoria +27120042701 Spain Barcelona +34 931815653 Spain Madrid +34 911883777 Sweden Stockholm +46 852500111 Switzerland Zurich +41 435006262 United Kingdom London +44 2033556363 United States Albuquerque, NM (505) 225-8243 United States Charlotte, NC (980) 202-0283 United States Charlotte, NC (980) 236-0398 United States Chicago, IL (312) 253-4880 United States Houston, TX (713) 474-2323 United States Kansas City, MO (913) 951-0932 United States Los Angeles, CA (213) 221-3799 United States New York, NY (646) 843-6969 United States Phoenix, AZ (602) 354-9444 United States San Diego, CA (619) 330-9640 United States San Francisco, CA (650) 360-0999 United States Santa Barbara, CA (805) 308-9649 United States Seattle, WA (206) 420-5904 United States Spokane, WA (509) 931-0459 United States Tacoma, WA (253) 343-1529
We’ve barely scratched the surface of what you can do with Incredible PBX for Issabel. Head over to our introductory article where we’ve documented dozens of Asterisk® applications that await your exploration. Enjoy!
Published: Tuesday, August 29, 2017
Need help with Asterisk? Visit the PBX in a Flash Forum.
